Homsee 70.9" Electric Standing Desk with Drawer and Cabinet User Manual

1. Ievads

This manual provides comprehensive instructions for the Homsee 70.9" Electric Standing Desk with integrated drawer and cabinet. This height-adjustable desk is designed for home office use, offering a spacious workspace and versatile storage solutions. Please read this manual thoroughly before assembly and operation to ensure safe and correct usage.

Figure 1: Homsee 70.9" Electric Standing Desk (Grey)

This image displays the Homsee 70.9" Electric Standing Desk in a grey finish, showcasing its L-shape design with a spacious desktop, an integrated side cabinet, and the electric height adjustment mechanism.

2. Drošības informācija

Svarīgi drošības norādījumi:

• Pirms lietošanas vienmēr pārliecinieties, ka galds ir pilnībā salikts un stabils.
• Nepārsniedziet maksimālo svara ierobežojumu uz galda virsmas — 150 kg (330 mārciņas).
• When adjusting the height, use the preset buttons carefully to avoid collisions with objects above or below the desk.
• Regulējot augstumu, turiet bērnus un mājdzīvniekus prom no galda.
• Always follow the assembly instructions provided to prevent injuries and ensure proper function.
• Nesēdiet un nestāviet uz galda.
• Ensure all cables are managed to prevent entanglement during height adjustments.

3. Iepakojuma saturs

The Homsee Electric Standing Desk is typically shipped in two boxes. Please verify that all components listed below are present and undamaged before beginning assembly.

• Desktop panels
• Electric lifting columns and motor
• Control panel with preset buttons
• Side cabinet components (panels, drawer, doors, shelves)
• All necessary assembly hardware (screws, bolts, tools)
• Detailed installation instructions guide

4. Uzstādīšana un montāža

Assembly of the Homsee Electric Standing Desk requires careful attention to the provided step-by-step instructions. It is recommended to have two people for assembly due to the size and weight of some components.

1. Izpakojiet sastāvdaļas: Carefully unpack all parts from both boxes. Lay them out on a clean, soft surface to prevent scratches.
2. Review Norādījumi: Read the entire assembly guide before starting. Identify all parts and hardware.
3. Salieciet rāmi: Follow the instructions to assemble the industrial-grade steel frame and attach the electric lifting columns.
4. Salieciet skapi: Construct the side cabinet, including the drawer and shelves. Note that the cabinet design is reversible, allowing you to configure it on either the left or right side of the desk.
5. Pievienot darbvirsmu: Securely attach the desktop panels to the assembled frame and cabinet.
6. Savienojiet elektroniku: Connect the motor and control panel according to the wiring diagram in the assembly guide. Ensure all connections are secure.
7. Pēdējās pārbaudes: Before use, ensure all screws are tightened, and the desk is stable.

Figure 2: Desk Dimensions Overview

This diagram illustrates the key dimensions of the Homsee Electric Standing Desk, including the desktop length, depth, and height adjustment range, as well as the dimensions of the integrated drawer and cabinet.

5. Lietošanas instrukcijas

The Homsee Electric Standing Desk features an intuitive control panel for height adjustment and memory presets.

5.1. Augstuma regulēšana

• Adjusting Up: Nospiediet un turiet UP (^) pogu, lai paceltu galdu vēlamajā stāvēšanas augstumā.
• Adjusting Down: Nospiediet un turiet DOWN (v) pogu, lai nolaistu galdu vēlamajā sēdēšanas augstumā.
• The desk's height can be adjusted smoothly between 29.5 inches and 44 inches.

5.2. Atmiņas iestatījumi

The control panel includes three preset buttons (1, 2, 3) to store and recall your preferred sitting and standing heights.

1. Lai saglabātu augstumu: Pielāgojiet galdu vēlamajam augstumam. Nospiediet "M" or "IESTATĪT" button (if available, otherwise proceed to step 2) followed by one of the preset buttons (1, 2, or 3). The display will show "S-" followed by the number, indicating the height is saved.
2. Lai atcerētos augstumu: Press the corresponding preset button (1, 2, or 3). The desk will automatically move to the saved height.

5.3. Collision Avoidance Feature

The desk is equipped with a collision-avoiding feature. If the desktop encounters an obstruction during adjustment, it will automatically stop and reverse slightly to prevent damage. Clear any obstructions before resuming adjustment.

Figure 3: Control Panel for Height Adjustment

This image shows the desk's control panel, featuring UP/DOWN arrows, three memory preset buttons (1, 2, 3), and a display for current height.

6. Apkope

Regular maintenance helps ensure the longevity and optimal performance of your Homsee Electric Standing Desk.

• Tīrīšana: Noslaukiet galda virsmas ar mīkstu, damp cloth. The engineered MDF with a sleek finish is water-resistant and easy to clean. Avoid using abrasive cleaners or harsh chemicals, which can damage the finish.
• Stiprinājumu pārbaudes: Periodiski pārbaudiet visas skrūves un bultskrūves, lai pārliecinātos, ka tās ir stingri pievilktas. Ja nepieciešams, pievelciet tās atkārtoti.
• Kabeļu vadība: Ensure power cords and other cables are neatly managed and do not interfere with the desk's movement.
• Motora kopšana: The electric motor is designed for durability. Avoid overloading the desk, which can strain the motor.

7. Traucējummeklēšana

If you encounter issues with your Homsee Electric Standing Desk, refer to the following troubleshooting tips:

• Galds nekustas:
  • Check if the power cord is securely plugged into both the desk and a working wall outlet.
  • Pārliecinieties, ka nav šķēršļu, kas kavē kustību.
  • If the control panel display shows an error code, consult the full assembly manual for specific error interpretations.
• Nevienmērīga kustība:
  • Pārliecinieties, vai rakstāmgalds ir novietots uz līdzenas virsmas.
  • Check that all assembly fasteners are securely tightened.
• Collision Avoidance Activation:
  • If the desk stops and reverses, it has detected an obstruction. Remove the obstruction and try adjusting the height again.
• Drawer/Cabinet Issues:
  • If drawers are stiff or misaligned, check the drawer slides for proper installation and ensure no objects are blocking their path.
  • Ensure cabinet doors are properly hinged and aligned.

For persistent issues or problems not covered here, please contact Homsee customer support.

8. Specifikācijas

9. Garantija un atbalsts

Homsee offers a limited warranty for this product. For specific details regarding warranty coverage, duration, and terms, please refer to the warranty card included with your product or contact Homsee customer service.

For technical support, assembly assistance, or to make a warranty claim, please contact Homsee customer service through their official website or the retailer where the product was purchased. Please have your model number (B0BGPLKPC6) and purchase date available when contacting support.

10. Oficiālie produktu video

Šobrīd šim modelim nav pieejami oficiāli pārdevēja produktu video.
