ZEISS SFL 8x30 binokļa lietošanas pamācība

1. Ievads

The ZEISS SFL 8x30 Binoculars are designed for lightweight, compact, and high-performance observation. Featuring Ultra-High Definition coated glass, these binoculars provide 90% light transmission for bright, high-contrast images, even in low-light conditions. The SmartFocus concept allows for rapid and precise focusing. This manual provides essential information for the proper setup, operation, and maintenance of your ZEISS SFL 8x30 binoculars.

2. Produkts beidziesview

Binocular Components

Familiarize yourself with the main components of your ZEISS SFL 8x30 binoculars:

• Objektīvie lēcas: Front lenses that gather light.
• Acu aizsargi: Adjustable for comfortable viewar vai bez brillēm.
• Fokusa ritenis: Central wheel for adjusting image sharpness.
• Dioptriju regulēšana: Ring on one eyepiece for compensating individual eye differences.
• Siksnas stiprinājumi: Kakla siksnas stiprinājuma punkti.
• Tilts: Connects the two optical tubes, allowing interpupillary distance adjustment.

2.1. attēls. Priekšpuse view of the ZEISS SFL 8x30 Binoculars, showing the objective lenses and central focus mechanism.

2.2. attēls: Tuvplāns view of an eyepiece with the adjustable eyecup extended.

Figure 2.3: Detail of the central focus wheel and ZEISS branding.

Iekļauti aksesuāri

Your ZEISS SFL 8x30 binoculars come with the following accessories:

• Kakla siksna
• Aizsargājošs somiņa pārnēsāšanai
• Objektīvu vāciņi
• Eyepiece rain guard
• Tīrīšanas lupatiņa

Figure 2.4: All included accessories for the ZEISS SFL binoculars.

3. Iestatīšana

3.1 Kakla siksnas piestiprināšana

1. Thread the ends of the neck strap through the strap lugs on each side of the binocular body.
2. Secure the strap by passing it back through the buckle, ensuring it is tightly fastened.
3. Adjust the strap length for comfortable carrying around your neck.

3.2 Acu aizsargu regulēšana

The eyecups can be adjusted to provide the optimal eye relief for comfortable viewing.

• Lietotājiem bez brillēm: Rotate the eyecups counter-clockwise until they are fully extended.
• Lietotājiem ar brillēm: Rotate the eyecups clockwise until they are fully retracted. This allows your eyes to be closer to the eyepieces, providing a full field of view.

3.3 Starpzīlīšu attāluma regulēšana

The interpupillary distance (the distance between the centers of your pupils) must be set correctly to see a single, circular image.

1. Turiet binokli līdz acīm.
2. Bend the binocular body at the hinge until you see a single, perfectly circular field of view.

3.4. Dioptriju regulēšana

This adjustment compensates for differences in vision between your left and right eyes.

1. Aizveriet labo aci vai aizsedziet labo objektīvu.
2. Ar kreiso aci skatieties caur binokli uz tālu objektu.
3. Rotate the central focus wheel until the image is sharp for your left eye.
4. Aizveriet kreiso aci vai aizsedziet kreiso objektīvu.
5. Look through the binoculars with your right eye at the same distant object.
6. Adjust the diopter ring (usually on the right eyepiece) until the image is sharp for your right eye.
7. The diopter setting is now calibrated for your eyes. You should only need to use the central focus wheel for subsequent observations.

4. Darbība

4.1. Fokusēšana

Once the interpupillary distance and diopter are set, focusing is straightforward:

1. Raise the binoculars to your eyes.
2. Atrodiet vēlamo objektu.
3. Rotate the central focus wheel until the object appears sharp and clear. The SmartFocus concept allows for quick adjustments with minimal rotation.

Figure 4.1: Users observing wildlife with ZEISS SFL binoculars.

4.2. attēls: Piemample of the clear and detailed view provided by ZEISS SFL binoculars.

5. Apkope un kopšana

5.1 Lēcu tīrīšana

The lenses of your ZEISS SFL binoculars feature advanced coatings for optimal performance. Proper cleaning is crucial to maintain their quality.

1. Remove loose dust: Use a soft brush or a blower bulb to gently remove any loose dust or particles from the lens surfaces.
2. Clean smudges: For fingerprints or stubborn smudges, breathe lightly on the lens surface to create condensation, then gently wipe with the provided microfiber cleaning cloth. Use circular motions from the center outwards.
3. Izvairieties no agresīvām ķīmiskām vielām: Never use abrasive cloths, paper towels, or harsh cleaning solutions, as these can damage the lens coatings.

The ZEISS T* coating ensures brilliant, high-contrast images, especially in challenging light conditions. The LotuTec coating provides a clear view in wet weather by repelling water and dirt from the lens surface.

Figure 5.1: Visual representation of the clarity provided by ZEISS T* coating.

Figure 5.2: Water beading on a lens with LotuTec coating, illustrating its water-repellent properties.

5.2 Vispārīga tīrīšana un uzglabāšana

• Wipe the binocular body with a soft, damp audums netīrumu vai putekļu noņemšanai.
• Store the binoculars in their protective case when not in use to prevent dust accumulation and physical damage.
• Izvairieties no uzglabāšanas tiešos saules staros vai ekstremālā temperatūrā.
• The binoculars are waterproof; however, after exposure to water, dry them thoroughly before storing.

Figure 5.3: ZEISS SFL binoculars demonstrating their waterproof capability in a natural environment.

6. Traucējummeklēšana

7. Specifikācijas

8. Garantija un atbalsts

ZEISS products are manufactured to high-quality standards and come with a manufacturer's warranty. For specific warranty details, registration, or technical support, please refer to the official ZEISS webvietnē vai sazinieties tieši ar viņu klientu apkalpošanas dienestu.

Tiešsaistes atbalsts: Visit the official ZEISS webvietne ar bieži uzdotajiem jautājumiem, produktu reģistrāciju un kontaktinformāciju.

Serviss un remonts: In case of a defect or the need for repair, please contact ZEISS customer service for authorized service centers and procedures.
