Ikarao Karaoke Machine Shell S1 - 280W Instruction Manual

Ievads

Welcome to the instruction manual for your Ikarao Karaoke Machine Shell S1. This portable home system is designed to deliver a premium audio experience with its 280W 2.2-channel speaker, 10.1-inch lyrics display, and two wireless self-charging microphones. This manual provides essential information for setting up, operating, and maintaining your device to ensure optimal performance and enjoyment.

The Ikarao Shell S1 offers versatile connectivity options including HDMI, USB, AUX, WiFi, and Bluetooth 5.3, making it suitable for various entertainment setups. Enjoy features like adjustable EQ, autotune, and preloaded KaraFun membership for a professional-grade karaoke experience.

Kas atrodas kastē

• 1 x Shell S1 Smart Karaoke Machine
• 2 x Bluetooth Wireless Microphones
• 1 x Portable Shoulder Strap
• 1 x Type C Cable (Charger not included)
• 1 x Lietotāja rokasgrāmata

Iestatīšana

1. Sākotnējā uzlāde: Before first use, fully charge the karaoke machine using the provided Type C cable. Connect the cable to the DC 15V input port on the rear panel and plug it into a compatible USB power adapter (not included).
2. Mikrofona uzlāde: Place the two wireless microphones into their designated charging slots located under the top lid of the machine. The microphones feature a magnetic self-charging design. An indicator light on the microphone will show charging status.
3. Ieslēgšana: Open the top lid to reveal the 10.1-inch screen. Press and hold the power button on the front control panel of the main unit. The screen will display the Ikarao logo as it boots up.
4. Wi-Fi savienojums: Once the system is powered on, navigate to the settings menu on the 10.1-inch screen to connect to your local Wi-Fi network (2.4G/5G supported). This is essential for accessing online content like YouTube and KaraFun.

Image: Ikarao Karaoke Machine Shell S1 with its 10.1-inch screen open, revealing the charging slots for the two wireless microphones. The main unit features a speaker grille and control panel.

Lietošanas instrukcijas

Galvenās ierīces vadības ierīces

• Barošanas poga: Nospiediet un turiet, lai ieslēgtu/izslēgtu ierīci.
• Bluetooth poga: Activates Bluetooth pairing mode for connecting external devices.
• Basa poga: Toggles the bass boost feature for enhanced low-frequency sound.
• Režīma poga: Cycles through different input modes (Bluetooth, AUX, Local Play).
• Skaļuma regulators: Rotates to adjust the master volume of the speaker. The LED ring around the knob indicates the volume level.

Image: Close-up of the rear panel of the Ikarao Karaoke Machine, displaying various connectivity ports including HDMI, USB, AUX, and the DC power input.

Mikrofona lietošana

• Ieslēgšana/izslēgšana: Lai ieslēgtu vai izslēgtu katru mikrofonu, nospiediet un turiet ieslēgšanas/izslēgšanas pogu.
• Skaļuma kontrole: Use the '+' and '-' buttons on the microphone to adjust its individual volume.
• Balss efekti: The system offers various voice effects accessible via the screen interface or dedicated buttons. Options include: Original, Karaoke (with echo), Super, Professional, Monster (deep voice), Popular, Cartoon (high-pitched voice), and Custom (adjustable reverb, treble, bass).

Image: The two wireless microphones are securely placed in their magnetic charging slots within the Ikarao Karaoke Machine, indicating their self-charging capability.

Screen Interface and Apps

The 10.1-inch built-in touchscreen provides access to various functions and applications:

• Sing Menu: Access Media Player for local files, YouTube for karaoke videos (requires Wi-Fi), and Media Library for pre-installed songs.
• Lietotņu izvēlne: Features pre-installed apps like KaraFun (6-month membership included) and YouTube. You can also download other compatible apps.
• Iestatījumi: Adjust display brightness, sleep time, check wireless mic battery levels, and configure HDMI settings. Sound settings allow control over tone volume, wireless mic volume, and mic modes. Wi-Fi settings manage network connections.

Image: The Ikarao Karaoke Machine with its 10.1-inch screen open, showing the user interface with icons for Media Player, YouTube, and other applications.

Savienojamība

The Shell S1 offers multiple ways to connect your audio and video sources:

• HDMI: Connect to a TV or external display to mirror the screen for a larger karaoke experience.
• USB: Atskaņot multividi files tieši no USB diska.
• AUX: Connect external audio devices via an auxiliary cable.
• Bluetooth 5.3: Wirelessly stream audio from your smartphone, tablet, or other Bluetooth-enabled devices.
• WiFi 2.4G/5G: Access online streaming services and content.
• Ģitāras ieeja: Plug in a guitar for live jam sessions.

Skaņas režīmi

Adjust the audio output to suit your environment and preferences:

• Hi-Fi: Standard high-fidelity audio.
• Gaisma: A lighter sound profile.
• Āra: Optimized for outdoor use, enhancing projection and clarity.
• Bass: Emphasizes low frequencies for a deeper sound.

Apkope

• Tīrīšana: Use a soft, dry cloth to clean the exterior of the machine and screen. Avoid abrasive cleaners or solvents.
• Akumulatora kopšana: To prolong battery life, avoid fully discharging the unit frequently. Store in a cool, dry place when not in use for extended periods.
• Uzglabāšana: When storing, ensure the top lid is closed to protect the screen and microphones.

Problēmu novēršana

• Nav jaudas: Ensure the unit is fully charged or connected to a power source. Check the power button.
• Nav skaņas: Check the master volume knob and individual microphone volumes. Ensure the correct input mode is selected.
• Mikrofons nepievienojas: Ensure microphones are charged and powered on. Re-pair them if necessary.
• Wi-Fi problēmas: Verify your Wi-Fi network is active and the correct password is entered in the settings.
• Screen Mirroring Problems: Ensure your TV or external display is set to the correct HDMI input.

Specifikācijas

Garantija un atbalsts

For warranty information and customer support, please refer to the contact details provided on the product packaging or the official Ikarao webSaglabājiet pirkuma čeku kā pirkuma apliecinājumu jebkādu garantijas prasību gadījumā.
